    Product Details:

    Place of Origin: China Shenzhen
    Brand Name: KeepGuard
    Certification: FCC/CE/RoHs/WEEE
    Model Number: KG760

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Price: Negotiable
    Payment Terms: Western Union, L/C, T/T
    Supply Ability: 10000pcs per month
    Contact Now
    Detailed Product Description
    Material: Pvc Color: CAMO
    Range: 20-25m Weight: 0.65

    KG760 SPECIFICATIONS


    Maximum image size12MP
    LensF=7.36;F/NO:2.8; FOV=55°Auto IR-Cut-Remove(at night)
    IR-Flash Range20m-25m; 28 LEDS
    Display Screen2.4 inch Color Display
    Memory CardSD or SDHC Card, Maximum capacity 32GB
    Internal memory32M
    Image Size12MP(4000×3000);8MP(3264×2448);5M(2592X1944); 3M (2048X1536);
    Video Size1280×720; 640×480;320×240;
    PIR SensitivityPIR with 3sensitivity levels:High/ Normal/ Low
    OperationDay/Night
    Response Time0.6 s
    Battery life12 months
    Triggering Interval1sec-60min programmable
    Shutter Speed1/10-1/2000sec.
    Shooting Numbers1-3 programmable
    Video Length5-60sec. programmable
    Power Supply8×AA recommended;4×AA as emergency power
    Stand-by current<0.28mA
    Power Consumption<180mA(+600mA when IR-LED Lighted)
    Timed Scanprogrammable
    Temperature Displayprogrammable
    Passwordprogrammable
    Moon Displayprogrammable
    Audio Videoprogrammable
    User InterfaceLCD display
    InterfaceUSB;SD card holder; 6V DC external;TV out(NTSC/PAL)
    SecurityStrap;1/4-20 attachment
    Operating Temperature-20-60℃(Storage temperature:-30-70℃)
    Operating Humidity5%-90%
    Security AuthenticationFCC/CE/RoHs/WEEE




    Surveillance Monoculars Night Vision Rifle Scopes for Scouting Game

    Company Profile
    Keepway Industrial(Asia)Co.,Ltd was established in 2003, is one of the most experienced and innovative companies focusing in R&D, agent and sale of digital video products and electronic products. KeepwayIndustrial has brands: KEEPGUARD and CEDO etc. KEEPGUARD focus in HD hunting camera, MMS and SMS hunting camera, wireless hunting camera, security camera and other customized camera. Our R&D center and factory are in Shenzhen. Also we have market center in Hong Kong. Backed by high productivity we can make highquality electronic products for customers. We have many years of OEM/ODM expertise.
    Image sensor5 Megapixel HD color CMOS
    lensf=7.36mm F/NO: 3.2 FOV=55°, auto IR-cut-remove (at night)
    IR-flash range20m-25m, 33 LEDs
    Display screen2.4 inch color display
    Memory cardSD or SDHC card, maximum capacity 32GB
    Image size12MP(4000×3000), 8MP(3264×2448), 5MP (2592X1944), 3MP (2048X1536)
    Video size1920*1080P/30fps
    PIR sensitivityPIR with 3 sensitivity levels: High/normal/low and auto
    OperationDay/night
    Battery life12 months
    Pre-salesWe have the self-manufactured equipment for PIR test
    We can control the detective angle, triggered time, and sensor distance
    Every year, ISO will come to make assessment for the whole production process
    Ensure incoming quality control, product quality and process control, internal audit and training meet International standardization organization’s requirement
    Incoming quality control: include vendor quality inspection and audit, incoming quality inspection
    Now our ISO system is ISO 9001: 2008
    We have 5000 square meter standard workshops in Guanlan, Shenzhen, have the modernized assembly line, have staff more than 200
    For safe and efficiency of production, every operator is requested to wear ESD wrist strap, especially when in handling ESD sensitive materials
    One of the most important point in process of production is the test for audio recorder
    Our workers will tapped pencil on the camera ceaselessly when the camera is in video mode
    This test is for the stability and articulation of the audio
    Our staffs dress the dust-proof clothing uniformly, wear the mouth-muffle and cap, before someone enter in the factory, he should wear clean shoe cover
    In such dust-free workshop, we can ensure that potential threat will not affect quality of cameras
    So our production efficiency can achieve 40,000 pieces per month
    Aging room: we have a 20 square meter room specially for test
    Each batch of products will be tested strictly more than 8 hours without a stop
    Items of the test include PIR sensitivity, startup speed, response time, IR-flash range
    Furthermore we have some machines for the packing
    Welding machine is for blister packaging
    This makes variety of our package, also we can control the quality
    Ultrasonic drilling machine is for waterproof
    It can connect black acrylic and enclosure together
    Compared with ordinary sticky, this way is more effective, almost can be seamless connection
    After the cameras come out from the assembly line
    Our QC will make sampling inspection
    Each batch of products is delivered with attached certificate and quality inspection report
    Except the conventional performance measuring, we also do limit test
    For waterproof, we will put camera in the machine for 72 hours
    According to the test, our camera’s waterproofing grade can reach at least IP54
    Many test is like this, such as high-low temperature test, anti-corrosion test, drop test, humidity test
    Also our clients can test them personally or let third-party testing company to give a test report
    For shipment, we support all kinds of courier service, DHL, FedEx, TNT, UPS
    We work together with DELTEC and Panalpina, one of the world's largest freight forwarders
    Our company has office in Hong Kong, so it is also convenient for us to cooperate with logistics company in Hong Kong
    After-salesWe have a warranty card
    During warranty, hardware failure occurring, which caused by product itself, we will provide free maintenance service for the customer
    Free warranty is for the first year
    If there is a need for repair, you should offer warranty card
    We will collect information on functions or usage non-scheduled, and try to satisfy the most clients’ requirements
    For high-quality clients, they have the first priority to our up-to-date products
    Furthermore, we have a three packs of policy
    Our goods are guaranteed returns for 7 days, replacement for 15 days, repair for one year
    FAQ: basic camera functions

    Camera stops taking images or won’t take images
    Check the batteries to make sure that they are new alkaline or Lithium AA batteries
    See note above about short battery life
    Make sure that the camera power switch is in the “On” position and not in the “Off” or “Setup” modes
    Make sure that you are using a good quality SD card in your camera
    We recommends SD Cards up to 32GB (class 6 or higher for 1920x1080 or 1280x720 HD video)
    If the SD card has its write protect switch in the lock position, the camera will not take images
    If you have used an SD card in another device before inserting it in your camera, you might want to try formatting the card using the “Format” parameter in setup mode (make sure you have backed up any important files first, as formatting will erase all previous files)
    In some cases, other devices may change the formatting of the SD card so that it will not work properly with the camera
