Long Range Performance Night Vision Rifle Scopes Infrared Monocular
Product Details:
Place of Origin: China Shenzhen
Brand Name: KeepGuard
Certification: CE,ROHS, FCC
Model Number: KG780
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Gift box
Delivery Time: 5-10 days
Payment Terms: Western Union, L/C, T/T
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
High Light:

Digital Night Vision Monocular


Infrared Binoculars


HD 12MP trail hunting camera

HD 12MP trail hunting camera for animal observation
·1080P GPRS day/night operation
·Up to 1 year standby power life
·Over 10 years of OEM/ODM experience
·Independent R&D team developed a Fresnel lens with up to 30m induction distance

Photo recording:

Photo resolution: 12MP, 8MP, 5MP and 3MP
Capture number (multi-shot): 1-3 programmable
Photo stamp: time, day, moon, temperature, keep-guard logo
Capture mode: color by day, black and white by night

Video recording:

Video resolution: 1920x1080, 1280*720,720*480
File format: AVI
Video length: 5-60sec, programmable
Audio video: yes


f=7.36mm, FOV=55°
Auto IR-cut-remove (at night)


LCD display: 2.4” color display
TV output computer output: USB2.0, net cable connect

Time system:
Shutter speed: 1/10-1/2000 second
Trigger time: <0.6 second
Trigger interval: 1-59sec, 1-60min, programmable
Timed scan: 2X

Night time illumination system:

IR-flash range: 20-25M
IR-LED: 33pcs no glow (940nm) IR LEDs

Detection system:

Motion sensor: PIR
Detection range: 20-25M

Power supply:

Power consumption: <200mA (+600mA when IR-LED lighted)

Security Use

As valuable as this camera is for wildlife surveillance, it is even more valuable as a security camera
Put the camera up overlooking your business, watching your house while you are on vacation, on a gate entering or exiting your property and countless​
Packing list
1.Digital camera
2.USB cable
3.Belt strap
4.Warranty card
5.Instruction manual





Image sensor 5 Megapixel HD Color CMOS
lens f=7.36mm F/NO: 3.2 FOV=55°, auto IR-cut-remove (at night)
IR-flash range 20m-25m, 33 LEDS
Display screen 2.4 inch color display
Memory card SD or SDHC card, maximum capacity 32GB
Image size 12MP(4000×3000), 8MP(3264×2448), 5M(2592X1944), 3M (2048X1536)
Video size 1920*1080P/30fps
PIR sensitivity PIR with 3 sensitivity levels: High/normal/low & auto
Operation Day/night
Battery life 12 months
Pre-sales 1. We have the self-manufactured equipment for PIR test
We can control the detective angle, triggered time, and sensor distance.
2. Every year, ISO will come to make assessment for the whole production process
Ensure incoming quality control, product quality and process control, internal audit and training & more meet International standardization organization’s requirement
Incoming quality control: include vendor quality inspection and audit, incoming quality inspection. Now our ISO system is ISO 9001: 2008.
3. We have 5000 square meter standard workshops in Guanlan, Shenzhen, have the modernized assembly line, have staff more than 200.
For safe and efficiency of production, every operator is requested to wear ESD wrist strap, especially when in handling ESD sensitive materials
One of the most important point in process of production is the test for audio recorder
Our workers will tapped pencil on the camera ceaselessly when the camera is in video mode
This test is for the stability and articulation of the audio.
Our staffs dress the dust-proof clothing uniformly, wear the mouth-muffle and cap, before someone enter in the factory, he should wear clean shoe cover
In such dust-free workshop, we can ensure that potential threat will not affect quality of cameras. So our production efficiency can achieve 40000pcs per month.
4. Aging Room: we have a 20 square meter room specially for test
Each batch of products will be tested strictly more than 8 hours without a stop
Items of the test include PIR sensitivity, startup speed, response time,IR-flash range etc.
Furthermore we have some machines for the packaging
Welding machine is for blister packaging
This makes variety of our package, also we can control the quality
Ultrasonic drilling machine is for waterproof
It can connect black acrylic and enclosure together
Compared with ordinary sticky, this way is more effective, almost can be seamless connection.
5. After the cameras come out from the assembly line
Our QC will make sampling inspection
Each batch of products is delivered with attached certificate and quality inspection report
Except the conventional performance measuring, we also do limit test
For waterproof, we will put camera in the machine for 72 hours
According to the test, our camera’s waterproofing grade can reach at least IP54
Many test is like this, such as high-low temperature test, anti-corrosion test, drop test, humidity test
Also our clients can test them personally or let third-party testing company to give a test report.
6. For shipment, we support all kinds of courier service, DHL, FedEx, TNT, UPS & more
We work together with DELTEC and Panalpina, one of the world's largest freight forwarders
Our company has office in Hong Kong, so it is also convenient for us to cooperate with logistics company in Hong Kong.
After-sales 1. We have a warranty card
During warranty, hardware failure occurring, which caused by product itself, we will provide free maintenance service for the customer
Free warranty is for the first year
If there is a need for repair, you should offer warranty card.
2. We will collect information on functions or usage non-scheduled, and try to satisfy the most clients’ requirements.
3. For high-quality clients, they have the first priority to our up-to-date products.
4. Furthermore, we have a three packs of policy
Our goods are guaranteed returns for 7 days, replacement for 15 days, repair for one year.
FAQ: basic camera functions
Camera stops taking images or won’t take images
Check the batteries to make sure that they are new alkaline or lithium AA batteries. See note above about short battery life.
Make sure that the camera power switch is in the “on” position and not in the “off” or “Setup” modes.
Make sure that you are using a good quality SD card in your camera. We recommends SD Cards up to 32GB (class 6 or higher for 1920x1080 or 1280x720 HD video).
If the SD card has its write protect switch in the lock position, the camera will not take images.
If you have used an SD card in another device before inserting it in your camera, you might want to try formatting the card using the “Format” parameter in setup mode (make sure you have backed up any important files first, as formatting will erase all previous files)
In some cases, other devices may change the formatting of the SD card so that it will not work properly with the camera.

Long Range Performance Night Vision Rifle Scopes Infrared Monocular 0Long Range Performance Night Vision Rifle Scopes Infrared Monocular 1Long Range Performance Night Vision Rifle Scopes Infrared Monocular 2
