Surveillance Monoculars Night Vision Rifle Scopes for Scouting Game
Product Details:
| Place of Origin: | China Shenzhen |
| Brand Name: | KeepGuard |
| Certification: | FCC/CE/RoHs/WEEE |
| Model Number: | KG760 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Payment Terms: | Western Union, L/C, T/T |
| Supply Ability: | 10000pcs per month |
|
Detail Information |
|||
| Material: | Pvc | Color: | CAMO |
|---|---|---|---|
| Range: | 20-25m | Weight: | 0.65 |
| High Light: | Infrared Binoculars,Night Scope Binoculars |
||
Product Description
KG760 SPECIFICATIONS
| Maximum image size | 12MP |
| Lens | F=7.36;F/NO:2.8; FOV=55°Auto IR-Cut-Remove(at night) |
| IR-Flash Range | 20m-25m; 28 LEDS |
| Display Screen | 2.4 inch Color Display |
| Memory Card | SD or SDHC Card, Maximum capacity 32GB |
| Internal memory | 32M |
| Image Size | 12MP(4000×3000);8MP(3264×2448)；5M(2592X1944); 3M (2048X1536); |
| Video Size | 1280×720; 640×480;320×240； |
| PIR Sensitivity | PIR with 3sensitivity levels:High/ Normal/ Low |
| Operation | Day/Night |
| Response Time | 0.6 s |
| Battery life | 12 months |
| Triggering Interval | 1sec-60min programmable |
| Shutter Speed | 1/10-1/2000sec. |
| Shooting Numbers | 1-3 programmable |
| Video Length | 5-60sec. programmable |
| Power Supply | 8×AA recommended;4×AA as emergency power |
| Stand-by current | <0.28mA |
| Power Consumption | <180mA(+600mA when IR-LED Lighted) |
| Timed Scan | programmable |
| Temperature Display | programmable |
| Password | programmable |
| Moon Display | programmable |
| Audio Video | programmable |
| User Interface | LCD display |
| Interface | USB;SD card holder; 6V DC external;TV out(NTSC/PAL) |
| Security | Strap;1/4-20 attachment |
| Operating Temperature | -20-60℃(Storage temperature:-30-70℃) |
| Operating Humidity | 5%-90% |
| Security Authentication | FCC/CE/RoHs/WEEE |
Company Profile
Keepway Industrial(Asia)Co.,Ltd was established in 2003, is one of the most experienced and innovative companies focusing in R&D, agent and sale of digital video products and electronic products. KeepwayIndustrial has brands: KEEPGUARD and CEDO etc. KEEPGUARD focus in HD hunting camera, MMS and SMS hunting camera, wireless hunting camera, security camera and other customized camera. Our R&D center and factory are in Shenzhen. Also we have market center in Hong Kong. Backed by high productivity we can make highquality electronic products for customers. We have many years of OEM/ODM expertise.
| Image sensor | 5 Megapixel HD color CMOS |
| lens | f=7.36mm F/NO: 3.2 FOV=55°, auto IR-cut-remove (at night) |
| IR-flash range | 20m-25m, 33 LEDs |
| Display screen | 2.4 inch color display |
| Memory card | SD or SDHC card, maximum capacity 32GB |
| Image size | 12MP(4000×3000), 8MP(3264×2448), 5MP (2592X1944), 3MP (2048X1536) |
| Video size | 1920*1080P/30fps |
| PIR sensitivity | PIR with 3 sensitivity levels: High/normal/low and auto |
| Operation | Day/night |
| Battery life | 12 months |
| Pre-sales | We have the self-manufactured equipment for PIR test We can control the detective angle, triggered time, and sensor distance Every year, ISO will come to make assessment for the whole production process Ensure incoming quality control, product quality and process control, internal audit and training meet International standardization organization’s requirement Incoming quality control: include vendor quality inspection and audit, incoming quality inspection Now our ISO system is ISO 9001: 2008 We have 5000 square meter standard workshops in Guanlan, Shenzhen, have the modernized assembly line, have staff more than 200 For safe and efficiency of production, every operator is requested to wear ESD wrist strap, especially when in handling ESD sensitive materials One of the most important point in process of production is the test for audio recorder Our workers will tapped pencil on the camera ceaselessly when the camera is in video mode This test is for the stability and articulation of the audio Our staffs dress the dust-proof clothing uniformly, wear the mouth-muffle and cap, before someone enter in the factory, he should wear clean shoe cover In such dust-free workshop, we can ensure that potential threat will not affect quality of cameras So our production efficiency can achieve 40,000 pieces per month Aging room: we have a 20 square meter room specially for test Each batch of products will be tested strictly more than 8 hours without a stop Items of the test include PIR sensitivity, startup speed, response time, IR-flash range Furthermore we have some machines for the packing Welding machine is for blister packaging This makes variety of our package, also we can control the quality Ultrasonic drilling machine is for waterproof It can connect black acrylic and enclosure together Compared with ordinary sticky, this way is more effective, almost can be seamless connection After the cameras come out from the assembly line Our QC will make sampling inspection Each batch of products is delivered with attached certificate and quality inspection report Except the conventional performance measuring, we also do limit test For waterproof, we will put camera in the machine for 72 hours According to the test, our camera’s waterproofing grade can reach at least IP54 Many test is like this, such as high-low temperature test, anti-corrosion test, drop test, humidity test Also our clients can test them personally or let third-party testing company to give a test report For shipment, we support all kinds of courier service, DHL, FedEx, TNT, UPS We work together with DELTEC and Panalpina, one of the world's largest freight forwarders Our company has office in Hong Kong, so it is also convenient for us to cooperate with logistics company in Hong Kong |
| After-sales | We have a warranty card During warranty, hardware failure occurring, which caused by product itself, we will provide free maintenance service for the customer Free warranty is for the first year If there is a need for repair, you should offer warranty card We will collect information on functions or usage non-scheduled, and try to satisfy the most clients’ requirements For high-quality clients, they have the first priority to our up-to-date products Furthermore, we have a three packs of policy Our goods are guaranteed returns for 7 days, replacement for 15 days, repair for one year |
| FAQ: basic camera functions | Camera stops taking images or won’t take images Check the batteries to make sure that they are new alkaline or Lithium AA batteries See note above about short battery life Make sure that the camera power switch is in the “On” position and not in the “Off” or “Setup” modes Make sure that you are using a good quality SD card in your camera We recommends SD Cards up to 32GB (class 6 or higher for 1920x1080 or 1280x720 HD video) If the SD card has its write protect switch in the lock position, the camera will not take images If you have used an SD card in another device before inserting it in your camera, you might want to try formatting the card using the “Format” parameter in setup mode (make sure you have backed up any important files first, as formatting will erase all previous files) In some cases, other devices may change the formatting of the SD card so that it will not work properly with the camera |
