IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable

IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable

IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable
IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable
IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable
Product Details:
Place of Origin: China Shenzhen
Brand Name: KeepGuard
Certification: FCC/CE/RoHs/WEEE
Model Number: KG695D
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: Negotiable
Packaging Details: 20pcs per carton
Delivery Time: 2-15days
Payment Terms: T/T, Paypal,Alipay
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Response Time: 0.25s Image Size: 30MP(6400*4800);16MP(4736*3552);5M (2592*1944);
Triggering Interval: 1sec-60min Programmable Operating Temperature: -20-60°c(Storage Temperature:-30-70°c)
Operating Humidity: 5%-90% IR-Flash Range: 25-30m
IR LED: 4*940nm Big IR LEDs Shutter Speed: 1/10-1/2000s
High Light:

IP67 Wildlife Infrared Trail Camera

,

Smtp Programmable Infrared Trail Camera

,

30MP Night Vision Hunting Camera

Trail camera Specification



Maximum image size 30MP
Lens f=7.36mm F/NO:2.8 FOV=55°; Auto IR-Cut-Remove (at night)
IR-Flash Range 25m-30m; High Power LED : 4LEDS
Display Screen 2.4 inch HD Color Display
Memory Card SD or SDHC Card, up to 64GB
Image Size 30MP(6400x4800);16MP(4736×3552);5M (2592X1944);
Video Size 1920*1080;1280*720 ;640*480;
PIR Sensitivity PIR with 4 sensitivity levels:High/ Normal/ Low/Auto
Operation Day/Night
Response Time Picture trigger:< 0.25 s ;Video trigger: <0.6s;
Triggering Interval 1sec-60min programmable
Shutter Speed 1/10-1/2000sec.
Shooting Numbers 1-9 programmable
Video Length 5-60sec. programmable
Power Supply 8×AA recommended; DC12V
Stand-by Current <75uA
Power Consumption <140mA(500mA when IR-LED Lighted)
Timed Scan programmable
Temperature Display programmable
Camera Name Input
Moon Display programmable
Audio Video programmable
User Interface LCD display
Interface USB;SD card;
Security Strap;1/4-20 attachment
Operating Temperature -20-60℃(Storage temperature:-30-70℃)
Operating Humidity 5%-90%
Security Authentication FCC/CE/RoHs/WEEE
Waterproof IP67



Wildlife Camera Quick Start



Move the latches and open the front cover
Load 8 lithium AA or alkaline AA batteries
Insert the SD card
Switch to the SETUP Mode
Press MENU button
Press UP or DOWN key to select Camera or Video Mode
Put it good position
Switch to the ON Mode and it have started working.



Hunting Camera INTRODUCTION



This KEEPGUARD CAM is the best-selling scouting camera which is designed for activity and is

resistant against water and snow. It is equipped with built-in infrared LEDs, so that it can be  triggered by any movement  in a location, then take high quality pictures or video clips.



Loading Batteries

After opening the two latches on the right side of the camera, you will see that it has 8 battery slots.

For maximum battery life, we recommend using 8 lithium AA or alkaline AA batteries.



Using an External Power Source

Optionally, you can connect an external 6V DC power source to the "DC In" jack at the bottom of camera.

It is recommended to use a power source with a current output greater than 1000mA. Please make sure

that the polarity is correct.



Inserting SD Card

This camera have 32MB internal memory, which is for camera upgrade. Insert the SD card ( OFF mode )

before beginning to operate the camera. SD card is supported up to maximum 32GB capacity.



Formatting the SD card

Formatting the SD card removes all files on the memory card and prepares for camera. Press the MENU,

then RIGHT or LEFT key several more times to move to the “Format” parameter setting menu. Press OK

key to enter sub-menu, Press the UP or DOWN key to highlight YES and press OK.



THE OFF, ON, and SETUP MODES

The KEEPGUARD CAM has three basic operational modes:

OFF Mode

The OFF mode is the "safe" mode when any actions must be taken, e.g. replacing the SD card or batteries,

or transporting the device. You will use OFF mode if you connect the camera to a computer's USB port

to download your photos/videos.

ON Mode

Once in ON mode no manual controls are needed or possible (the control keys have no effect). The

KEEPGUARD CAM will take photos or videos automatically (according to its current parameter settings)

when it is triggered by the PIR sensor′s detection of activity in the area it covers.

SETUP Mode

In the SETUP mode you can check and change the settings of the KEEPGUARD CAM with the help of

built-in LCD. Moving the power switch to the SETUP position will turn on the LCD display and you will see an information screen.



Fig. 1: SETUP Information Screen

IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable 0

SETUP Mode Shortcut Keys

  1. First switch to the SETUP Mode.
  2. Press MENU button.
  3. Press RIGHT or LEFT key scrolls to the next or previous parameter.
  4. Press UP or DOWN key to select setting for the currently parameter.
  5. Press OK to save the new setting.
  6. Then switch to ON Mode to take photos or videos.

IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable 1





Trail Camera Performance:

Wholesale IP67 Night Vison Digital Trail Hunting non-wireless Security Camera

IP67 outdoor hunting camera Infrared wildlife Camera Night Vision Deer 30MP Programmable 3
