Scout Hunting Camera Low Consumption Trail Cam , The Fast Reponse Time <0.3s

Infrared Hunting Camera
High Light:

Infrared Motion Camera


Hunting Surveillance Cameras


WEEE Approved Scout Hunting Camera



Maximum image size16MP
LensF=7.36;F/NO:2.8; FOV=55°Auto IR-Cut-Remove(at night)
IR-Flash Range20m-30m; 36 LEDS
Display Screen2.4 inch HD Color Display
Memory CardSD or SDHC Card, Maximum capacity 32GB
Internal memory128M
Image Size16MP(4608x3456);8MP(3264×2448);3M (2048X1536);
Video Size1280×720; 640×360;
PIR SensitivityPIR with 3sensitivity levels:High/ Normal/ Low
Response Time<0.3 s
Battery life12 months
Interval0.6s.1s-60m programmable
Shutter Speed1/10-1/2000sec.
Capture Numbers1-9 programmable
Video Length5-60sec. programmable
Power Supply8×AA recommended
Stand-by current<0.09mA
Power Consumption<180mA(+800mA when IR-LED Lighted)
Timed Scanprogrammable
Temperature Displayprogrammable
Moon Displayprogrammable
Audio Videoprogrammable
User InterfaceLCD display
InterfaceUSB;SD card holder;
SecurityStrap;1/4-20 attachment
Operating Temperature-20-60℃(Storage temperature:-30-70℃)
Operating Humidity5%-90%
Security AuthenticationFCC/CE/RoHs/WEEE

Detection Circuit
It is tough to improve much over the detection circuit of the 2012 keepGuard KG760NV Cam. In 2013, it remains a very long detection range(20m-25m).
The trigger speed is 0.7 seconds,which is one of the fastest trigger on the market. The recovery is 3.0 seconds. This remains one of the finest recovery times on the market.
The PIR sensor, which controls the detection zone, was improved for 2013. The detection range is at least 60 ft in most cases.
Overall, this is an excellent detection circuit without a weakness. It can provide adequate coverage in any camera trap station you can think up.

Picture Quality
The day pictures from the KeepGuard are very nice.the maximum pixels can reach 12MP. Color, clarity and focus are exactly what we like to see.
The night pictures are surprisingly clear and bright, especially for this no glow trail camera . You can click on any of the images below to see exactly what we are talking about.
Battery Life
Battery life has long been one of the biggest strengths of the KeepGuard Trail Cams. This camera is no different. Low stand-by current and low day and night power consumptions. This camera is a rock star when it comes to battery consumption.

stand-by currentDaytime Current DrawNighttime Current Draw
<0.28 ma<200 ma<800 ma

ma = milliamps
Operating on 8 AA
batteries, this camera will last a long time in the field. With lithium batteries, you can expect anywhere from 8-12 months in the field. Alkaline batteries do work in this camera, however, from their low tolerance for cold weather we always use nimh rechargeables or lithium batteries. Depending on your preference, all three battery types will work.

Ease of Use
You won't have a problem setting the 2013 KeepGuard KG860NV HD up. The options are simple and user-friendly. At the same time,It has more programming (timing) options than the competition.
Durability is still outstanding. We have experienced minimal returns on this unit and in years past the KeepGuard cameras had very low return rates. All in all, the durability of the 2013 KeepGuard KG760NV is outstanding.
With the latest firmware in this camera, we believe the 2013 KeepGuard KG760NV is still a tremendous value. Quick trigger time, excellent recovery, top-notch battery life and durability to last.
This camera is a workhorse, throw in a set of batteries and an SD card and let this camera go to work for you.
