12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer

12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer

    • 12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer
    • 12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer
  • 12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer

    Product Details:

    Place of Origin: China Shenzhen
    Brand Name: KeepGuard
    Certification: CE,ROHS, FCC
    Model Number: KG870

    Payment & Shipping Terms:

    Minimum Order Quantity: 20pcs
    Price: Negotiable
    Packaging Details: Gift box, Carton
    Delivery Time: 3-7 days
    Payment Terms: Western Union, L/C, T/T
    Supply Ability: 1000pcs per month
    Contact Now
    Detailed Product Description
    Image Sensor: 5MP HD Color CMOS Display Screen: 2.4 Inch Color Display
    Image Size: 12MP;8MP;5MP;3MP Response Time: 0.6s
    Video Size: 1920*1080p MMS Mode: Instant/Fixed Time
    High Light:

    Wildview Game Camera


    Infrared Deer Camera

    12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer
    About KeepGuard KG760NV Trail Camera
    You won't have a problem setting the 2013 KeepGuard KG860NV HD up.  The options are simple and user-friendly. At the same time,It has more programming (timing) options than the competition.
         Durability is still outstanding.  We have experienced minimal returns on this unit and in years past the KeepGuard cameras had very low return rates.  All in all, the durability of the 2013 KeepGuard KG760NV is outstanding.
         With the latest firmware in this camera, we believe the 2013 KeepGuard KG760NV is still a tremendous value.  Quick trigger time, excellent recovery, top-notch battery life and durability to last.
         This camera is a workhorse, throw in a set of batteries and an SD card and let this camera go to work for you.
    Picture Quality
         The night pictures  are surprisingly clear and bright, especially for this no glow trail camera .  You can click on any of the images below to see exactly what we are talking about.
         The day pictures from the KeepGuard are very nice.the maximum pixels can reach 12MP. Color, clarity and focus are exactly what we like to see.
     12MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer 012MP Hunting Motion Sensor Camera Digital Wildlife Camera for Deer 1
    Battery Life
         Battery life has long been one of the biggest strengths of the KeepGuard Trail Cams.
         This camera is no different.  Low stand-by current and low day and night power consumptions.
         This camera is a rock star when it comes to battery consumption.

    stand-by currentDaytime Current DrawNighttime Current Draw
    <0.28 ma<200 ma<800 ma

    ma = milliamps
         Operating on 8 AA
     batteries, this camera will last a long time in the field.  With lithium batteries, you can expect anywhere from 8-12 months in the field.  Alkaline batteries do work in this camera, however, from their low tolerance for cold weather we always use nimh rechargeables or lithium batteries.  Depending on your preference, all three battery types will work.

    Detection Circuit
         It is tough to improve much over the detection circuit of the 2012 keepGuard KG760NV Cam.  In 2013, it remains a very long detection range(20m-25m).
         The PIR sensor, which controls the detection zone, was improved for 2013.  The detection range is at least 60 ft in most cases.
         The trigger speed is 0.7 seconds,which is one of the fastest trigger on the market. The recovery is 3.0 seconds. This remains one of the finest recovery times on the market.
         Overall, this is an excellent detection circuit without a weakness.  It can provide adequate coverage in any camera trap station you can think up.

    Packaging & Delivery

    Packaging Details:20 piecs cameras in one carton:50*33*33.5mm
    Delivery Detail:1-7days

    Technical Specification

    KeepGuard-KG870NV Technical Specifications

    Image Sensor

    5 Megapixel Color CMOS

    Maximum Pixel Size



    f=7.45mm;FOV=55°;  F/NO:2.8; Horizonal View Angel =42°;
    Auto IR-Cut-Remove (at night)

    IR-Flash Range

    Up to 25m/82ft (36 LEDs)

       Display Screen

    2.4” Color Display

    External Memory

    SD/SDHC Card (Max.32GB)

    Internal Memory


    PIR Sensitivity

    PIR with 4 Sensitivity Level: High/Normal/Low/Auto

    Image Size

    12MP(4000X3000);      8MP(3264X2448);
       5MP(2592X1944);     3MP (2048X1536);

    Video Size

    1920X1080;   1280X720;    848X480;

    Response Time

    <0.6 Second

    Night Vision
    Shutter Speed

    1/10~1/2000 Second

    IR-LED Control


    Trigger Interval

    1~59 sec.;1~60min; Programmable

    Shooting number

    1~3  Programmable

    Video Length



    USB2.0, SD Card Holder;9V DC External;

    Power Supply

    8xAA recommended; 4xAA as emergency power

    Stand-by Current


    Power Consumption

    < 200mA
    (+600mA when IR-LED lighted)


    Strap;1/4-20 attachment

    Operating Temperature

    -20 ~ +60℃(Storage temperature:-30 ~ +70℃)

    Operating Humidity

    5% ~ 90%
