Portable Thermal Vision Scope , Image Thermal Monocular For Hunting

Portable Thermal Vision Scope , Image Thermal Monocular For Hunting

  • Portable Thermal Vision Scope , Image Thermal Monocular For Hunting
Portable Thermal Vision Scope , Image Thermal Monocular For Hunting
Product Details:
Place of Origin: GUANGDONG
Brand Name: KEEPGUARD
Certification: FCC CE ROHS
Model Number: KG510IR
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 20 PCS PER CARTON
Delivery Time: 3-7 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 PCS PER WEEK
Contact Now
Detailed Product Description
Name: Thermal Vision Scope Detector Type: 400 ×300@17 μm
Feature: Portable Focus: 19mm
Focusing: Free FOV: 19.0°×14.5°
Screen: Colorful 0.2″LCOS Application: Thermal Monocular For Hunting
High Light:

infrared thermal scope

,

thermal vision monocular

Portable Thermal Vision Scope , Image Thermal Monocular For Hunting



Thermal Vision Scope Features



· Small size, one hand operation

· Live transmission via WIFI, APP real-time browsing, recording, photographing, playback and other operations on smartphone

· IP66 protection, one meter drop resistance

· Hot-spot tracking function support

· Built-in multiple color palettes and crosshair indicator



Thermal Vision Scope Introduce



It's time to upgrade your KG510lR series. Connectedto mobile APP via Wi-Fi, the new KG510lR series canbe remote controlled to display synchronously, take photos and videos. Compared with the last version, it provides superior image, longer detection range andadvanced algorithm, helping to pick up the targets.



Thermal Vision Scope Application


Hunting /Law enforcement/Outdoor /Patrol/
Search & Rescue/Personal Security



Thermal Vision Scope Parameters



Item KG510IR N1 KG510IR N1 WIFI KG510IR N2 KG510IR N2 WIFI
Detector
Detector Type 400 ×300@17 μm
Spectral Range 8μm~14 μm
Lens
Focus 19mm 25mm
Focusing free Manual
FOV 19.0°×14.5° 14.6°×11.1°
Screen Colorful 0.2″LCOS
Viewfinder Monocular, diopter adjustable±4
Frame 50Hz
Digital Zoom ×2, ×4
Color Palette Black hot, white hot, red hot 1, red hot 2, red hot 3
Fuctions
Photograph × × × ×
Additional functions Illuminator or laser
pointer or neither
Illuminator or laser
pointer or neither
Illuminator or laser
pointer or neither
Illuminator or laser
pointer or neither
Cross cursor
Image enhancement × ×
Wi -Fi × ×
Zoom
Freeze × ×
Charging indicator
Active indicator ×
Power
Battery Internal Li -ion battery,3.7V,3200mAh
Working Time ≥5h
Adapter Standard USB power adapter, max 10W
Interface
USB Charging
Video Output MCX Connector,PAL /NTSC
Environment Characteristics
Working Temperature -10℃~50℃
Storage Temperature -30℃~60℃
Humidity 10%~95%
Shock 10Hz~150Hz~10Hz 0.15mm IEC60068 -2-6
Encapsulation IP66
Drop 1m drop N/A
Physical Parameter
Weight 350g 375g
Size 160mm ×67mm ×62mm 168mm ×67mm ×62mm
Package
Standard accessories thermal imager/ power adapter/ USB cable/ video cable /lens cap/ wrist strap/shoulder strap/ soft drawstring bag/ user manual
Optional accessories N/A 40mm extender lens (FOV:9.3°×7.0°)
Detection Range
Human :1.8m ×0.5m 500m 700m
Vehicle:2.3m ×2.3m 1300m 1700m
Recognition Range
Human :1.8m ×0.5m 300m 350m
Vehicle:2.3m ×2.3m 500m 700m



Details



Portable Thermal Vision Scope , Image Thermal Monocular For Hunting 0
